UPPER CONTROL ARMS – LEXUS LX570 2008-2021 LEXUS LX570 SUSPENSION

KITS FEATURES

UCA’s are designed with added caster to aid in retaining factory alignment specs when aftermarket lift kits are installed. This reduces the darting or wandering in the vehicle’s steering when 2.5”-3” lift kits are installed.

Upper control arms combined with extended length coilover shocks will allow for up to 1” of additional wheel droop travel.

Will work with all aftermarket brand shocks.

Only upper control arm on the market that allows a 3.0″ diameter coilover shock to be installed with no contact.

Urethane bushings reduce bushing deflection compared to stock rubber bushings.

4130 chromoly tubular upper control arms are 100% bolt on.

CNC tapered spindle adapters convert the factory ball joint to a 1″ uniball for added component strength & maximum wheel travel.

TOTAL CHAOS includes 1″ I.D. uniballs that feature a heat-treated stainless-steel ball & heat-treated stainless-steel race for maximum corrosion resistance and component longevity. These uniballs also feature a military grade PTFE woven fabric liner that helps prevent noise.

Custom profile upper and lower hi-misalignment spacers maximize droop wheel travel and are machined from heat treated 17-4 stainless steel.

Control arm pivots include zerk fittings to grease the bushings and inner sleeves without disassembly.

3 stage powder coat process includes a durable clear coat to provide a long lasting finish.

Hand crafted in the U.S.A.

Complete Grade 8 hardware kit is included.

NOT COMPATIBLE WITH FACTORY AHC SYSTEM.

Upper Control Arm fits: 2008 LX570, 2009 LX570, 2010 LX570, 2011 LX570, 2012 LX570, 2013 LX570, 2014 LX570, 2015 LX570, 2016 LX570, 2017 LX570, 2018 LX570, 2019 LX570, 2020 LX570, 2021 LX570.
