Description
Lifting the front of a vehicle with a set of coilovers may be step one in gaining more off-road performance, however installing just an aftermarket shock can limit performance without upgrading the Upper Control Arm too.
Our UCA’s are designed to add caster – offering better straight line tracking, as well as improved high speed stability and cornering. TC upper arms add component durability and allow for individual parts to be replaced including bushings and uniballs..
KITS FEATURES
TC upper control arms combined with extended length coil over shocks will allow for up to 1″ of additional wheel travel.
Designed to maintain factory alignment specs on vehicles with 1.5″-3″ lift kits.
4130 chromoly tubular upper control arms are 100% bolt on.
1″ I.D. uniballs feature a heat-treated stainless-steel ball & heat-treated stainless-steel race for maximum corrosion resistance and component longevity. These uniballs also feature a military grade PTFE woven fabric liner that helps prevent noise and reduce maintenance.
CNC tapered spindle adapters convert the factory ball joint to a 1″ uniball for easy installation.
Custom profile upper and lower hi-misalignment spacers are machined from 17-4 stainless-steel to maximize strength and wheel travel.
Urethane bushings reduce deflection compared to stock rubber bushings.
Control arm pivots include zerk fittings to grease the bushings and inner sleeves without disassembly.
3 stage powder coat process includes a durable clear coat to provide a long lasting finish.
Complete Grade 8 hardware kit is included.
Not compatible with air ride or variable ride height models.
Hand crafted in the U.S.A.
4WD only. Not compatible on 2WD models.
Upper Control Arm fits: 2019 Ram 1500, 2020 Ram 1500, 2021 Ram 1500.
